TE Mate-AX Camera Cable to FAKRA and SMA
Built around the TE Connectivity Mate-AX single cavity automotive coaxial interface, this cable series uses 1-2310137-9 as the referenced Mate-AX configuration. Mate-AX, FAKRA and SMA options let engineers match the cable to the camera, ECU, prototype harness or test equipment already in use.
The range includes eight connector configurations and standard lengths of 0.1 m, 0.5 m, 1 m, 2 m, 3 m, 4 m and 5 m. Short leads fit bench fixtures and module connections, while longer versions give more freedom for prototype vehicle routing.
These are passive coaxial cable assemblies. They connect compatible interfaces but do not convert video formats, process signals or translate protocols.
Mate-AX Connections for Vehicle and Bench Use
Automotive camera projects often move between several connector environments. A camera or ECU may use Mate-AX, a vehicle harness may use FAKRA, and development equipment may present an SMA port.
The cable handles those interface changes directly. Mate-AX to Mate-AX versions stay within the same connector family, Mate-AX to FAKRA versions connect with compatible automotive coaxial harnesses, and Mate-AX to SMA versions provide access to compatible bench and test equipment.
Before ordering, confirm connector gender, Mate-AX coding, FAKRA coding and the mating interface on the actual device.
Mate AX Female to Mate AX Female – Blue
The blue female to female configuration is intended for systems that require a single cavity Mate AX female interface at both cable ends.
This version keeps both endpoints within the Mate AX architecture, supporting compatible camera modules, development fixtures and automotive equipment with matching interfaces.
The blue housing is part of the connector identification, so selection should be based on the required mating interface rather than color preference alone.
Mate AX Female to Mate AX Male
This version combines a Mate AX female connector with a Mate AX male interface, creating a direct male-to-female extension topology within the same connector family.
It is particularly useful when an existing Mate AX port needs to be moved away from the original device position, for example during camera relocation, prototype harness routing or test-fixture development.
Keeps the original Mate AX architecture without FAKRA or SMA transitions.
Mate AX Female to Mate AX Female – Black
The black version provides another Mate-AX female-to-female configuration for systems using the corresponding black coded interface.
Its role is not simply cosmetic. Color and mechanical coding help distinguish connector interfaces within multi-port automotive electronic systems and should therefore be matched to the intended equipment-side connector.
This configuration can help organize camera, ECU or validation harnesses where multiple similar coaxial connections are installed close together.
Mate AX Female to Mate AX Female – White
The white Mate-AX female-to-female cable provides a dedicated option for equipment designed around the corresponding white connector interface.
It is useful where the harness needs to preserve a defined connector identification from one device connection to another, especially in prototype assemblies and test setups containing several coaxial channels.
Before substitution, verify the mechanical coding and mating connector; housing colors alone do not confirm interchangeability.
Mate AX Female to FAKRA Female
This configuration transitions from a single-cavity Mate-AX female interface to a FAKRA female connector, linking two automotive coaxial connector families within one cable assembly.
It can be used where a Mate-AX equipped camera, ECU or development interface must connect into equipment or harness architecture designed around a compatible FAKRA mating connector.
Integrating both interfaces into one assembly can eliminate the need to stack a separate Mate-AX-to-FAKRA adapter together with an additional coaxial cable.
Mate AX Female to FAKRA Male
The FAKRA male version is intended for the opposite equipment-side gender requirement. It provides a direct transition between a Mate-AX female interface and a FAKRA male termination.
This topology is useful during vehicle camera integration when the Mate-AX side and existing automotive coaxial harness use different connector systems.
Match FAKRA gender and coding to the target camera, ECU or harness. Housing appearance alone does not confirm compatibility.
Mate AX Female to SMA Female
This version brings the Mate AX interface to an SMA female termination, making it particularly useful for engineering environments where automotive camera hardware must connect with compatible coaxial laboratory equipment.
Possible setups include prototype boards, interface fixtures, signal development hardware and validation benches equipped with an SMA mating port.
Unlike the FAKRA versions, this option is aimed mainly at development and bench access rather than vehicle harness integration.
Mate AX Female to SMA Male
The eighth configuration terminates the Mate-AX cable with an SMA male connector for equipment requiring the corresponding SMA female port.
It provides engineers with a compact way to bring an automotive Mate AX connection into compatible test or development hardware without adding an intermediate gender adapter.
This version is especially practical for repeatable bench setups where the Mate AX device remains fixed while different prototype, measurement or interface hardware is connected at the SMA side.
Typical Applications
Connector Options for Real Test Setups
Three Connector Families
One series covers Mate-AX, FAKRA and SMA, allowing the termination to follow the actual camera, vehicle harness or development-equipment interface.
Configuration Options
Blue, black and white Mate-AX options are combined with different gender and connector-family choices for more precise configuration control.
0.1 m to 5 m Length Range
Seven selectable lengths cover very short equipment connections, standard bench wiring and longer prototype vehicle routing.
Vehicle Flexibility
Native Mate-AX versions support same-family links, FAKRA variants address automotive harness integration, and SMA versions suit compatible engineering equipment.
Why This Cable Series Is Practical
● Select the Interface Around the Equipment
Instead of adapting the device to one fixed cable termination, engineers can select Mate-AX, FAKRA or SMA according to the actual mating port.
● Fewer Intermediate Adapter Connections
A direct Mate-AX to FAKRA or Mate-AX to SMA assembly can replace combinations that would otherwise require a separate adapter plus another coaxial cable.
● Better Configuration Control in Multi-Port Setups
Mate-AX housing color, connector family and gender can be specified individually, helping distinguish cable functions in prototype and validation environments.
● One Cable Family Across Different Development Stages
The same Mate-AX side architecture can be maintained while the opposite interface changes from Mate-AX to FAKRA or SMA as a project moves between module testing, vehicle integration and laboratory validation.
Why Are Mate-AX, FAKRA and SMA Offered in the Same Cable Series?
They serve different connection environments rather than representing three names for the same connector.
Mate-AX → Mate-AX: Keeps the connection inside the Mate-AX ecosystem.
Mate-AX → FAKRA: Creates an interface transition for compatible automotive coaxial equipment and harnesses.
Mate-AX → SMA: Provides an SMA termination that can be convenient for compatible engineering, prototype and laboratory hardware.
The correct version should therefore be selected according to the actual mating connector at both ends, not simply according to the application name "camera cable."
Does Connector Color Mean the Mate-AX Versions Are Interchangeable?
Not necessarily. The blue, black and white Mate-AX variants should not be treated simply as cosmetic color choices.
In an automotive connector system, housing color may be used together with mechanical coding and interface definition to distinguish connections. A cable that looks similar in size may therefore not be the correct mating version for another port.
For ordering, confirm: Mate-AX part number → Gender → Housing / Coding → Mating connector → Opposite connector → Cable length.
Choosing the Right Cable Length
| Length | Suggested Use |
|---|---|
| 0.1 m | Very short interface adaptation |
| 0.5 m | Compact bench or module connection |
| 1 m | General prototype and test setup |
| 2 m | Extended bench or in-vehicle routing |
| 3 m | Prototype vehicle installation |
| 4 m | Longer equipment-to-device routing |
| 5 m | Extended vehicle or laboratory setup |
Product FAQ
What is TE 1-2310137-9 in this cable series?
It is the referenced TE Connectivity Mate-AX connector configuration used for the Mate-AX side of this product family. Confirm the mating connector and required cable configuration before ordering.
Why are blue, black and white Mate-AX versions listed separately?
The housing versions are provided as separate selections because connector identification and coding can matter for mating compatibility. They should not be selected purely by preferred color.
Should I choose FAKRA male or FAKRA female?
Choose the FAKRA gender according to the mating connector on the target camera, ECU, harness or adapter. If uncertain, provide the equipment connector part number or a clear interface photo for confirmation.
When should I use Mate-AX to SMA instead of Mate-AX to FAKRA?
SMA termination is useful when the Mate-AX device needs to connect with compatible prototype, development or laboratory hardware using SMA. FAKRA is generally more relevant when connecting into a compatible automotive coaxial interface.
Are 0.1 m and 5 m cables used for the same type of installation?
They can use the same connector configuration, but the routing purpose is different. Short cables are useful for compact interface adaptation, while longer lengths provide more routing freedom for vehicle and laboratory setups.
Does this cable convert the camera video protocol?
No. It is a passive cable assembly and provides a physical coaxial connection between compatible interfaces. It does not actively convert video formats, protocols or electrical signaling.
Can I replace a blue Mate-AX cable with the black or white version?
Do not assume interchangeability from connector size alone. Verify the connector P/N, coding, gender and mating interface before substitution.
What information should I provide for a custom Mate-AX cable?
Provide the Mate-AX connector or mating P/N, opposite connector type and gender, required FAKRA coding if applicable, cable length, cable specification, application and quantity.
