Quad HFM to 4 FAKRA Automotive Coaxial Breakout Cable
The Quad HFM to 4 FAKRA Breakout Cable provides a practical interface between a compact four-channel HFM connection and four individual FAKRA coaxial ports. Its 1-to-4 breakout structure separates the four integrated coaxial channels into independent FAKRA branches for convenient signal access, routing and testing.
Designed for automotive electronics development and laboratory integration, this cable assembly is suitable for ADAS camera validation, ECU testing, HIL test benches, prototype vehicle wiring and multi-channel coaxial signal measurement.
Product Specifications
| Parameter | Specification / Details |
|---|---|
| Product Type | Automotive Coaxial Breakout Cable |
| Connector A | 1 × Quad HFM Straight Plug, Neutral Coding |
| Connector B | 4 × FAKRA Straight Jack, Neutral Coding |
| Configuration | 4-Channel, 1-to-4 Breakout |
| Cable Type | Automotive Coaxial Cable |
| Standard Length | 300 mm |
| Customization | Cable length, branch length, connector coding and labeling available on request |
4-Channel Quad HFM to FAKRA Interface Conversion
The Quad HFM to 4 FAKRA Breakout Cable provides a compact interface between a high-density four-channel HFM connection and individual FAKRA coaxial ports. Each integrated HFM channel is routed to a separate FAKRA branch, giving engineers direct access to all four signal paths.
The breakout configuration is especially useful in automotive development environments where individual channels need to be connected, disconnected, measured or diagnosed separately during camera validation, ECU development and laboratory testing.
Typical Applications
Product Features
4-Channel Breakout Design
Converts one Quad HFM interface into four individual FAKRA connections, providing convenient access to each coaxial signal channel.
Compact Multi-Channel Interface
The Quad HFM connector integrates four coaxial channels into one compact interface, helping simplify connections in space-conscious automotive test setups.
Independent Channel Access
Four separate FAKRA branches allow engineers to connect, identify, measure and troubleshoot each coaxial channel individually.
Compact 300 mm Configuration
The standard 300 mm configuration provides a compact connection between devices and test equipment while helping reduce excess cable routing on the bench.
Why Use a Quad HFM Breakout Cable?
-
Simplify Multi-Channel Connections
The Quad HFM interface combines four coaxial channels into one compact connection, while the four FAKRA branches provide direct access to each individual channel. This helps organize multi-channel connections on automotive development and test benches.
-
Bridge Quad HFM and FAKRA Interfaces
Provides a straightforward interface between equipment using a Quad HFM connection and devices or test equipment equipped with individual FAKRA coaxial ports.
-
Improve Channel-Level Testing
The 1-to-4 breakout structure allows engineers to independently connect, disconnect, measure and troubleshoot individual channels during prototype, camera and ECU development.
Product FAQ
Q1: What is the connector configuration of this cable?
A1: It uses one Quad HFM straight plug with neutral coding on one side and four individual FAKRA straight jacks with neutral coding on the breakout side.
Q2: Is this cable suitable for ADAS camera testing?
A2: Yes. The four-channel breakout structure is suitable for automotive camera development, signal access and ADAS test setups using compatible HFM and FAKRA interfaces.
Q3: Can the four FAKRA channels be accessed independently?
A3: Yes. Each channel from the Quad HFM interface is routed to an individual FAKRA branch for separate connection, measurement and troubleshooting.
Q4: Can the cable and branch lengths be customized?
A4: Yes. Premier Cable can provide custom main cable and branch lengths according to equipment layout and application requirements.
Q5: Are different FAKRA coding options available?
A5: Different FAKRA coding options are available upon request. Please provide the required mating interface or connector coding when ordering.
