The MS3116F-12-10P is a MIL-DTL-26482 Series I circular electrical connector featuring a bayonet-style quick-coupling mechanism. Its straight cable plug configuration incorporates 10 male pin contacts and mates with a compatible socket-contact receptacle having the correct shell size, contact arrangement, and polarization.

The connector features an olive-drab-style metal shell, a knurled coupling ring, and a rear cable clamp assembly. The clamp helps secure the cable and reduce the transfer of external pulling forces to the termination area, supporting organized wiring and equipment maintenance. It is suitable for evaluating in systems that require periodic disconnection, servicing, or harness replacement.

The MS3116F-12-10P provides 10 individual electrical contact positions within a single circular interface. Depending on the system wiring design, these contacts may be assigned to power, control, sensor signals, or auxiliary circuits. Actual circuit functions depend on the equipment's contact assignment and electrical requirements.

The bayonet coupling mechanism supports connection and disconnection through a prescribed mating and rotational locking procedure. The rear clamp helps stabilize the cable exit and reduce mechanical stress on the termination area. By consolidating multiple circuits into one standardized interface, the connector can simplify equipment wiring, interface management, and maintenance.

No. Even when the contact count is identical, shell size, contact arrangement, polarization, bayonet geometry, and series compatibility must be checked. Verify the mating receptacle using the complete part number and mechanical drawings before ordering.
