ZH23-19-22P-1-B is a newly developed 19 Pin ZH23 Bayonet Circular Connector from Premier Cable, designed for industrial automation, instrumentation, industrial electronics and Russian-standard connector replacement applications.

Featuring 19 female socket contacts, a Shell Size 22 metal housing and a Type 1 equipment-side receptacle configuration, this connector uses a bayonet coupling mechanism for secure mechanical engagement. Its multi-contact arrangement integrates multiple electrical circuits into a single detachable interface, helping simplify equipment wiring and connection management.

The product is identified by three corresponding part numbers: ZH23-19-22P-1-B, СНЦ23-19-22P-1-B and STNS23-19-22P-1-B, supporting model identification, spare-part sourcing and compatibility assessment across different markets.

The product is identified by three corresponding part numbers: ZH23-10-22P-6-B, СНЦ23-10-22P-6-B and STNS23-10-22P-6-B. These references help customers identify suitable connector configurations across different sourcing markets. Mechanical and electrical compatibility should be verified before replacement.

Unlike ordinary friction-fit connectors, the ZH23 10 Pin Bayonet Circular Connector combines mechanical locking, polarized mating and multi-contact connectivity in one rugged assembly. This helps reduce accidental disconnection during vibration, equipment movement and maintenance.

As an industrial connector manufacturer, Premier Cable supports custom ZH23 connectors, soldered cable assemblies, OEM development, sample evaluation and wholesale supply for equipment manufacturers and industrial system integrators.

Part Number Identification

Code	Description
ZH23	Connector Series
19	19 Contacts
22	Shell Size 22
P	Female Socket Contacts
1	Type 1 Equipment Receptacle

Product Features

The ZH23-19-22P-1-B features a 19-pin female socket configuration that integrates multiple control, monitoring, and signal transmission circuits into a single circular interface, supporting multi-contact industrial connections. Its Shell Size 22 metal housing provides mechanical support for the contacts, insulating components, and bayonet coupling mechanism, enhancing structural reliability.

The standard key polarization design ensures correct mating orientation and helps prevent mismating with incompatible connectors. Designed for fixed equipment-side installation, the Type 1 receptacle features a simplified rear attachment for convenient mounting and internal wiring integration, making it suitable for industrial control systems, instrumentation, and automation equipment.

Typical Applications

Industrial Automation Equipment

Suitable for PLC controllers, industrial automation machinery, production-line control modules and electromechanical systems. The 19-contact receptacle integrates multiple control or monitoring circuits into one interface, supporting standardized assembly, wiring management and maintenance.

Industrial Control Cabinets and Electronics

Suitable for equipment-side connections in industrial control cabinets, electronic enclosures and fixed control modules. The Type 1 receptacle supports organized interconnection between external cable assemblies and internal equipment wiring.

Russian-Standard Equipment Maintenance

Suitable for maintenance, spare-part sourcing and upgrades involving СНЦ23 or STNS23 connector references. Before replacement, verify the 19-contact arrangement, Shell Size 22, female socket contacts, standard polarization and equipment-side mounting configuration.

Product FAQ

What Is the Difference Between P and B Contacts ?

In the ZH23 ordering convention, P identifies female socket contacts, while B identifies male pin contacts. Therefore, ZH23-19-22P-1-B uses socket contacts, whereas ZH23-19-22B-1-B uses pin contacts.

What Is the Difference Between Type 1 and Type 6 ?

Type 1 is an equipment-side receptacle with a simplified rear attachment, while Type 6 is a cable plug with a straight cable-clamp attachment. Their mounting locations, rear structures and installation functions differ.

Which Industries Use This Connector ?

It is suitable for industrial automation, instrumentation, test and measurement, industrial electronics, data acquisition and Russian-standard equipment maintenance requiring centralized multi-contact electrical connections.

Does Premier Cable Offer Connector Customization ?

Yes. Premier Cable supports custom ZH23 connectors, mating cable assemblies, wire lengths, contact assignments, labeling, packaging and OEM manufacturing based on customer drawings and engineering requirements.
