ZH23-10-22P-6-B is a newly developed ZH23 Series 10-pin bayonet circular male plug from Premier Cable, designed for industrial automation, instrumentation, electrical control systems and Russian-standard connector replacement projects.

Featuring a Shell Size 22 metal housing, ten male contacts, Key Position B polarization and a straight plug configuration, this connector uses a bayonet coupling mechanism to provide secure mechanical retention. Its solder termination supports customized cable assemblies and equipment wiring, while gold-plated copper alloy contacts contribute to dependable electrical connectivity.

The product is identified by three corresponding part numbers: ZH23-10-22P-6-B, СНЦ23-10-22P-6-B and STNS23-10-22P-6-B. These references help customers identify suitable connector configurations across different sourcing markets. Mechanical and electrical compatibility should be verified before replacement.

Unlike ordinary friction-fit connectors, the ZH23 10 Pin Bayonet Circular Connector combines mechanical locking, polarized mating and multi-contact connectivity in one rugged assembly. This helps reduce accidental disconnection during vibration, equipment movement and maintenance.

As an industrial connector manufacturer, Premier Cable supports custom ZH23 connectors, soldered cable assemblies, OEM development, sample evaluation and wholesale supply for equipment manufacturers and industrial system integrators.

Technical Specifications

Parameter	Specification
Russian Part Number	СНЦ23-10-22P-6-B
Premier Cable P/N	ZH23-10-22P-6-B
Contact Type	Socket
Number of Contacts	10 Pin
Shell Size	22
Termination	Solder

Why Is This Connector Needed ?

Industrial equipment requires connectors that not only transmit electrical signals but also withstand vibration, mechanical stress and periodic maintenance. Conventional friction-fit connectors may loosen when subjected to external forces.

The ZH23-10-22P-6-B combines bayonet locking, Key Position B polarization, metal shell protection and ten solder-terminated contacts to provide a secure multi-contact interconnection solution for industrial controllers, test instruments and compatible Russian-standard equipment.

Core Performance Advantages

Reduced Risk of Accidental Disconnection

Bayonet coupling provides mechanical retention independent of contact friction, helping reduce loosening caused by vibration and routine handling and supporting more consistent equipment operation.

Improved Long-Term Contact Stability

Gold-plated copper alloy contacts provide favorable conductivity. When combined with proper soldering and contact-force design, they help maintain stable electrical connections and reduce intermittent signal failures.

Simplified OEM Cable Assembly Standardization

Consistent contact layouts, key positions and housing configurations support standardized OEM cable assemblies. Premier Cable offers custom wire lengths, wiring configurations, soldering services and bulk manufacturing based on project specifications.

Product FAQ

What Are the Corresponding Part Numbers ?

ZH23-10-22P-6-B, СНЦ23-10-22P-6-B and STNS23-10-22P-6-B are corresponding part number references. Mechanical and electrical compatibility should be confirmed before replacement.

What Is the Difference Between P and B Contact Types ?

In the ZH23 naming convention, P generally indicates socket contacts and B indicates pin contacts. However, the supplied specification identifies this particular model as having male contacts. The discrepancy must be resolved through contact-face drawings and engineering confirmation before ordering.

Is This Connector Suitable for Vibration Environments ?

The bayonet locking mechanism helps reduce loosening under vibration. For high-vibration equipment, confirm the required vibration rating and validate the mated connector and cable assembly.

Are Custom Cable Assemblies Available ?

Yes. Premier Cable supports OEM cable assemblies with custom lengths, wire gauges, contact assignments, rear protection, labeling and packaging, subject to engineering review.
