The ZH23-61-36B-1-B is a newly developed 61-contact circular electrical connector from Premier Cable's ZH23 series. It features a size 36 shell, pin contacts and a simplified tail attachment for equipment requiring a large number of organized electrical connections.

Its 61 contacts provide a consolidated interface layout for multiple electrical circuits, while shell size 36 identifies the corresponding mechanical configuration. Under the commonly used ZH23 series coding convention, this model uses a socket-style connector body with a simplified tail attachment and male pin contacts.

It can be evaluated for equipment interface integration, complex circuit organization and specialized harness development.

This connector establishes multiple electrical connections between an equipment interface and a compatible interconnection assembly. Its 61 male pin contacts can be assigned to different power, control or signal circuits according to the approved wiring diagram, allowing multiple circuits to be connected and managed through one interface.

For equipment with extensive wiring requirements, a multi-contact interface can reduce the complexity of distributing numerous separate connectors and support clearer circuit identification, harness planning and maintenance.

Technical Specifications

Parameter	Specification
Russian Part Number	СНЦ23-61-36B-1-B
Premier Cable P/N	ZH23-61-36B-1-B
Contact Type	Plug
Number of Contacts	61 Pin
Shell Size	36

Product Features

61-Contact High-Density Interface

This model features a 61-contact interface that organizes multiple electrical circuits within one connector. For equipment requiring numerous control lines, auxiliary circuits or signal channels, a consolidated contact layout supports a unified wiring and circuit-assignment scheme. The exact contact arrangement, numbering sequence and available circuit assignments must be verified against the official contact-layout drawing.

Size 36 Shell Configuration

The 36 in the part number identifies the shell-size configuration within the ZH23 series, distinguishing it from other mechanical variants. This designation helps engineers narrow down mating-part selection, installation-space planning and interface-dimension checks.

Product Capabilities and Customization

Multi-Contact Interface Configuration Review

Premier Cable can review connector configuration requirements using customer-provided equipment-interface drawings, contact layouts and mating part numbers. Changes to contact arrangement, mechanical dimensions or electrical ratings should undergo technical review before samples and production arrangements are confirmed.

OEM Customization and Bulk Supply

Premier Cable can discuss part-number verification, technical documentation, sample evaluation, customization, packaging identification and volume-supply planning with industrial equipment manufacturers, system integrators and purchasing teams. Customization scope, minimum order quantities, pricing and lead times depend on the product configuration and order requirements.

Product FAQ

What Type of Connector Is the ZH23-61-36B-1-B ?

The ZH23-61-36B-1-B is a newly developed 61-contact circular connector from Premier Cable's ZH23 series. It features a size 36 shell, male pin contacts and a simplified tail attachment. It can be evaluated for equipment requiring multiple electrical connections through one interface.

Why Does This Model Have Male Pin Contacts but a Receptacle Configuration ?

In the ZH23 series coding system, the overall connector construction and internal contact type are separate classification dimensions. 1 identifies the receptacle configuration, while B identifies male pin contacts. A receptacle configuration can therefore use male pin contacts. Verify the connector type, contact type and compatible mating part together when ordering.

How Can the Dimensions, Mating Life and Ingress Protection Be Confirmed ?

Request the official engineering drawing, technical specification and applicable test reports from Premier Cable. Housing dimensions, mechanical mating life, ingress protection and operating temperature must be confirmed using documentation applicable to this exact model rather than inferred from the series name or product appearance.

Does Premier Cable Offer Customization and Bulk Supply for This Model ?

Premier Cable can evaluate connector customization, OEM integration and bulk purchasing arrangements according to project requirements. Customers can provide the mating part number, contact-assignment drawing, equipment-interface requirements and estimated order quantity for technical review. Customization options, minimum order quantities, pricing and lead times are subject to formal confirmation.
