Products Description
The Advantech PCL-10251 compatible cable is a shielded industrial breakout cable designed to connect one 100-pin half-pitch SCSI interface to two 50-pin half-pitch SCSI interfaces. It is primarily intended for compatible Advantech motion-control cards, industrial controllers and DIN-rail wiring boards used in machine automation and industrial I/O systems.
The cable features one 100-pin male connector and two 50-pin male connectors, with 25 twisted pairs of stranded tinned-copper conductors and a drain wire. Aluminum/Mylar foil and braided-copper double shielding help reduce electromagnetic interference and signal crosstalk in electrically noisy industrial environments.
Specification
| Product Name | HPDB100 to HPDB50 Cable |
| Part No. | PCM-S-0759 |
|
Connector A |
HPDB 100Pin Male |
| Connector B | HPDB 50Pin |
| OD | 8.0mm |
| Wire | 28AWG*25PAIR+ADB |
|
Cable Length |
OEM |
| Compatible with |
Adavantech PCL-10251-1E Adavantech PCL-10251-2E Adavantech PCL-10251-3E |
Drawing
