Products Description
Molex 39-01-2225 22 Pin Multi-Branch Cable Tree Wire Harness
This custom multi-branch wire harness integrates a Molex 39-01-2225 22-position main connector with multiple Molex 35150-0100 1-position branch housings and terminal-ended circuits.
The cable tree is manufactured using 22AWG UL1452 wires in red, black and orange, with a nominal wire OD of 1.76 mm. Black PET braided sleeving, heat shrink tubing and cable ties provide organized routing and protection around the main cable section.
With multiple independent branches extending from one centralized 22-pin interface, this harness provides an organized solution for distributing low-current signal, monitoring and control circuits between a main controller and multiple electrical connection points.
Connector & Product Configuration
| Item |
Specification |
|---|---|
| Product No. |
|
| Main Connector |
|
| Branch Connector |
|
| Main Terminal |
|
| Branch Terminal | Molex 35745-0110 |
| TPA Retainer |
Molex 35182-0190 |
Key Product Advantages
Original Connector Part Number Integration
Built around Molex 39-01-2225 and 35150-0100 connector housings for a clearly defined multi-connector wiring configuration.
Multi-Branch Cable Tree
A centralized 22-position interface distributes multiple independent branches to different electrical connection points.
22AWG UL1452 Wiring
Uses 22AWG UL1452 wire with 1.76 mm OD in red, orange and black for organized circuit identification.
Protected Main Cable Section
Black PET braided sleeving and heat shrink tubing help organize and protect the main wire bundle.
Application Scenarios
Battery Management Systems
Multiple independent branches can be routed between a main control connector and individual monitoring or control circuits within a battery management system.
Control & Monitoring Systems
The 22AWG multi-branch construction is suitable for organized signal and low-current control connections where multiple independent circuits need to be distributed from one main interface.
Products Drawing
